Teltonika FMB001

FMB001 is tracking terminal with GNSS, GSM connectivity, and OBDII support, which is able to collect device coordinates and transfer them via GSM network to server. This device is perfectly suitable for applications, which need location acquirement of remote objects.

Show more

Location and tracking

  • GPS and GLONASS
  • Continuous mode only
  • LBS support

Mobile networks

  • Quad-band 900/1800 MHz; 850/1900 MHz
  • Only 2G networks

Power supply

  • External power supply
  • Build-in 170mAh Li-ion 3,7V backup battery

Inputs and outputs

  • 1 digital input for ignition status
  • OBDII connector
  • OBDII data reading

Notable features

OBDII data reading
FMB001 connects directly to car OBDII connector and is able to read up to 32 vehicle onboard parameters.

Bluetooth
Integrated Bluetooth enables wireless headset and various other Bluetooth sensors connectivity.
Make phone calls to Your employee via Bluetooth headset. No unauthorized calls anymore! Be sure that your employee is always safe and uses hands free headset instead of phone!

Supported up to 4 BLE temperature, humidity or fuel sensors.

Read records and configure your tracker wirelessly via Bluetooth
No inconvenient configuration via SMS or searching for tracker in hard to reach places to connect USB cable.
Single push and your device is connected to configurator via Bluetooth.

Micro SD card
Don’t lose any records with micro SD card up to 32 GB!
FMB010 will store all data in micro SD card when driving in areas where GSM is not available.

Advanced antitheft system
Prevent your vehicle from theft with advanced antitheft functionality. Combine Auto Geofencing with new Towing detection functionality.

Smart Crash detection
Ensure safety of Your employee with smart Crash detection. Get alarm message immediately after accident, save workers life!

Server Integration

EU platformtracker.navixy.com (52.57.1.136)
US platformtracker.us.navixy.com (13.52.37.2)
Server port47776

General information

PurposeVehicle
InstallationDIY
Special form factorOBDII Dongle

Housing

Size50x49x25 mm (1.97x1.93x0.98 in)

GNSS Location

Internal antenna (GNSS)Yes
GPSYes

Connectivity

Cellular network typeGSM Quad Band
Internal antenna (Connection)Yes
Cellular network generation2G

Interfaces

ACC/Ignition inputYes
Supported
Discrete inputsYes
Supported

Tracking features

Tracking modesContinuous
Location by Cell IDYes
Supported
OdometerYes
Supported
ECO drivingYes
Supported

Events monitoring

Car crashYes
Supported
TowingYes
Supported

Self monitoring

Network signal levelYes
Supported
GNSS signal levelYes
Supported
External power source voltageYes
Supported
Internal battery levelYes
Supported

CAN/OBDII reading

CAN/OBDII reader typeInternal
Supported
CAN/OBDII parametersFuel level, fuel consumption, engine RPM, throttle position, speed, coolant temperature and other

Remote management

Server connection setup over SMSYes
Supported
Remote device configurationYes (over GPRS)
Supported
Forced GNSS location update over SMSYes
On request
