Queclink GV300W INS

Queclink GV300W INS is a vehicle tracking device with support of A-GPS and GLONASS navigation. The device has a wide range of inputs and outputs, one RS232 interface and a socket for optional external GPS antenna. Queclink's firmware offers a lot of configurable options for working modes, detecting events, harsh behavior monitoring and other. Supports 3G network.

Mostrar más

The GV300W INS is a compact GNSS tracker designed for a wide variety of vehicle tracking applications. It has multiple I/O interfaces that can be used for monitoring or controlling external devices. Its built-in GNSS receiver has superior sensitivity and fast time to first fix. Its triple band WCDMA subsystem supports UMTS/HSDPA 850 (Band V)/1900 (Band II)/2100(Band I) MHz and GSM/GPRS 850/900/1800/1900 MHz allowing the GV300W INS’s location to be monitored in real time or periodically tracked by a backend server and mobile devices. Its built-in 3-axis accelerometer allows driving behavior monitoring, motion detection and extended battery life through sophisticated power management algorithms. System integration is straightforward as complete documentation is provided for the full-featured @Track protocol. The @Track protocol supports a wide variety of reports including emergency, geo-fence boundary crossings, driving behavior, low battery and scheduled GNSS position.

Pros

As a GPS tracker manufacturer, Queclink is well known for its functional devices with comprehensive firmware, and GV300W INS is not the exception. The firmware allows to configure a lot of options (including remote control over GPRS), detect a wide range of events, read data from CAN bus and digital fuel level sensors, use Garmin-compatible PND, monitor driving behavior. The firmware of Queclink GV300W INS can be updated OTA (Over-the-Air).

  • Adjustable working modes: tracking, sleeping
  • Self-monitoring: GPS/GSM/Battery levels
  • RS232 for digital devices: fuel level sensor, CAN bus reader, camera, Garmin-compatible PND
  • A wide range of detectable events (including tow, jamming)
  • Driver behavior monitoring based on accelerometer, speed and ignition
  • Rechargeable backup battery, 250 mAh
  • Over-the-Air firmware update
  • 3G support

Cons

  • There is only one RS232 serial interface, which can be a limitation if you want to connect multiple digital devices.
  • The absence of 1-wire interface makes it more difficult to control the temperature and identify drivers, though external RFID reader can be still connected to the RS232 interface.
  • Not waterproof. If you require IP-rated water resistance, check Queclink GMT100 or Queclink GMT200 models instead.

Integración de Servidor

Servidor de la EUtracker.navixy.com (52.57.1.136)
Servidor de la UStracker.us.navixy.com (13.52.37.2)
Puerto de servidor47764
Integrado21/06/2018

Información general

PurposeVehículo
InstalaciónProfesional

Alojamiento

Peso71 g (2.5 oz.)
Tamaño80x49x26 mm (3.15x1.93x1.02 in)

Localización GNSS

Antena interna (GNSS)
Antena externa (GNSS)Opcional
GPS
GPS asistido
Chipsetu-blox

Conectividad

Tipo de la red del celularUMTS/HSDPA 850/1900/2100, GSM/GPRS 850/900/1800/1900
Antena interna (Conexión)
Generación de red celular3G

Interfaces

Número de Interfaces RSC2321
Número de salidas3
Número de entradas (todos tipos)5
Entrada ACC/ignisión
Entradas digitales
Soportado
Entrada análoga
Soportado
Interfaz RS232
Salidas
Soportado

Características de hardware

Capacidad de batería250 mAh
Batería integrada
Acelerómetro

Hardware extras

Lectura del sensor del nivel de combustible
Soportado
Lectura del identificador del conductor
Soportado
Lectura del sensor de la temperatura externa
Soportado

Características de rastreo

Localización por Cell ID
Soportado
Consumo inteligente de batería
Soportado
Odómetro
Soportado
ECO driving
Soportado

Monitoreo de eventos

Poca batería
Soportado
Cambio de entrada
Soportado
Corte de alimentación externa
Soportado
Accidente de tráfico
Soportado
Remolque
Soportado

Automonitoreo

Nivel de señal
Soportado
Nivel de señal GNSS
Soportado
Satélites GNSS fijados
Soportado
Voltaje de alimentación externa
Soportado
Nivel de batería interna
Soportado

Leyendo CAN/OBDII

Parámetros CAN/OBDIISí, Fuel level, fuel consumption, engine RPM, throttle position, speed, engine load, coolant temperature, DTC error codes and other
Soportado
Lectura de códigos DTC
Soportado

Administración remota

La conexión con servidor por SMS
Soportado
Configuración remota de dispositivoSí (por GPRS), Sí
Soportado
Control remoto de las salidasSí (por GPRS), Sí
Soportado
Localización por LBS preferente a GPRS
Soportado
Localización forzada de GNSS por SMS
Soportado
