GoTrip TK100 is vehicle GPS tracker with a wide range of options to prevent the car stealing. It is suitable for personal use and fleet management when remote control of the vehicle is the most important. It has a built-in GPS and GSM antenna and some security options like towing sensor, SOS alarm, Tele-cut off function for petrol and electricity.
GoTrip TK100 is supplied to the customer in a cardboard box containing all the equipment that is necessary for operation.
The standard package contains:
- Power cord
- SOS alarm cable & button
- User Manual
Location and tracking
GoTrip TK100 is embedded with GPS, it doesn’t support GLONASS or alternative systems.
The tracking mode, which is supported by device, is tracking by time interval.
As the back-up, when no satellites signals are available, it uses Cell ID location (also known as LBS-tracking).
GoTrip TK100 has a Quad-band GSM 2G that allows to operate it all over the world.
GoTrip TK100 features a rechargeable 450 mAh battery. When fully charged it ensures about 3-5 hours of device operation (in normal conditions).
Local and remote management
GoTrip TK100 can not be controlled by GPRS. But there is a wide list of SMS commands in a human-friendly format, on which device always replies back. It supports remote APN settings configuration by SMS.
GoTrip TK100 has three LED indicating:
- Backup battery charge
- GSM/GPRS mode
- GPS signal reception
|EU platform||tracker.navixy.com (126.96.36.199)|
|US platform||tracker.us.navixy.com (188.8.131.52)|
|Weight||96 g (3.39 oz.)|
|Size||90x52x15 mm (3.54x2.05x0.59 in)|
|Internal antenna (GNSS)||Yes|
|Cellular network type||GSM Quad Band|
|Internal antenna (Connection)||Yes|
|Cellular network generation||2G|
|Number of outputs||1|
|Number of inputs (all types)||3|
|Battery capacity||450 mAh|
|Engine block relay||Yes|
|Location by Cell ID||Yes|
|External power cut off||Yes|
|Network signal level||Yes|
|GNSS signal level||Yes|
|External power source voltage||Yes|
|Server connection setup over SMS||Yes|
|Remote device configuration||Yes (over SMS)|
|Remote outputs control||Yes (over GPRS), Yes|
