D-TEG TX1000D

D-TEG TX1000D is a comapct and comfortable in use GPS tracker. This device has highly sensitive positioning solution for live vehicle tracking and reporting. D-TEG TX1000D also can be connected with an external Panic button.

Show more

Location and tracking

  • GPS/GLONASS support
  • Continuous tracking mode

Mobile networks

  • WCDMA BAND1(2100MHz), BAND8(900MHz)
  • 3G Network

Power supply

  • Cigar Jack

Inputs and outputs

  • 3 Digital inputs
  • 1 Output

Other features

  • External Panic button
  • Built-in GPS/GLONASS
  • Smart G-sensor and Gyro sensor

Server Integration

EU platformtracker.navixy.com (52.57.1.136)
US platformtracker.us.navixy.com (13.52.37.2)
Server port47695

General information

PurposeVehicle
InstallationDIY

Housing

Weight206 g (7.27 oz.)
Size91x56Ø mm (3.58x2.2 in)

GNSS Location

Internal antenna (GNSS)Yes
GPSYes
GLONASSYes

Connectivity

Cellular network typeWCDMA/BAND8
Internal antenna (Connection)Yes
Cellular network generation3G

Interfaces

Number of outputs1
Number of inputs (all types)3
ACC/Ignition inputYes
Supported
Discrete inputsYes
Supported

Hardware features

Emergency buttonYes
Supported

Tracking features

Tracking modesContinuous
ECO drivingYes
Supported

Remote management

Remote device configurationYes (over GPRS)
Supported
Remote outputs controlYes (over GPRS)
Supported
