Jointech JT709A

JT709A is a smart Bluetooth lock with 2G/4G connectivity, built-in GPS tracking, and a 4500 mAh rechargeable battery. It supports remote and offline unlocking, real-time location monitoring, route history playback, and remote configuration. Designed for logistics and cargo security, it offers a reliable and efficient solution for tracking and protecting mobile assets.


Server connection

EU platformtracker.navixy.com (52.57.1.136)
US platformtracker.us.navixy.com (13.52.37.2)
Server port47664
Auto registrationYes

General information

PurposeAsset
Weight390 g (13.76 oz.)
Size110x82x35 mm (4.33x3.23x1.38 in)
Waterproof classIP67
Internal antenna (GNSS)Yes

Connectivity information

Network signal levelYes
Network operator IDYes
Cellular network type4G LTE Frequency band: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/B19, 4G: FDD-LTE B1/B3/B5/B7/B8/B20, 4G: GSM/GPRS/EDGE 900/1800 MHz, 4G: TDD-LTE B38/B40/B41, 4G: WCDMA/HSDPA/HSPA+ B1/B5/B8, 2G: GSM/EDGE 850/900/1800/1900Mhz
Cellular network generation4G: LTE, 2G

Location information

GNSS signal levelYes
LBSYes
GPSYes

Features

Built-in batteryYes
Battery capacity4500 mAh
Activate a device on the platform Try it now
Haven’t found your device? We can add it Integrate
