Server connection
| EU platform | tracker.navixy.com (52.57.1.136) |
| US platform | tracker.us.navixy.com (13.52.37.2) |
| MENA platform | tracker.me.navixy.com (34.166.104.189) |
| Server port | 47776 |
| Auto registration | Yes |
General information
| Purpose | Vehicle |
Interfaces
| Digital inputs | 5 |
| Number of outputs | 2 |
| Analog sensor | Yes |
Features
| Auto Registration | Yes |
| Board Voltage | Yes |
| Led Control | Yes |
| Location Request | Yes |
| Gprs Location Request | Yes |
| Odometer | Yes |
| Gsm Lbs | Yes |
| Gsm Signal Level | Yes |
| Motion sensor | Yes |
| Apn Settings | Yes |
| Hardware key | Yes |
| Custom Fields | Yes |
| Zero Battery Level | Yes |
| Altitude | Yes |
| Sim Card | Yes |
| Satellites | Yes |
| Gsm Roaming | Yes |
State Fields
| State Fields |
|
Inputs and outputs
| avl_io_100000 | Yes |
| axis_x | Yes |
| axis_y | Yes |
| axis_z | Yes |
| battery_current | Yes |
| battery_voltage | Yes |
| board_voltage | Yes |
| can_alternator_current | Yes |
| can_ambient_air_temp | Yes |
| can_barometric_pressure | Yes |
| can_battery_level | Yes |
| can_cab_interior_temp | Yes |
| can_cargo_ambient_temp | Yes |
| can_charging_system_voltage | Yes |
| can_coolant_level | Yes |
| can_coolant_t | Yes |
| can_e_battery_health | Yes |
| can_e_charger_current | Yes |
| can_e_charger_current_actual | Yes |
| can_e_charger_energy | Yes |
| can_e_charger_voltage | Yes |
| can_e_charger_voltage_actual | Yes |
| can_e_current_range | Yes |
| can_e_electric_consumption | Yes |
| can_e_full_battery_capacity | Yes |
| can_e_remain_battery_capacity | Yes |
| can_e_remaining_charge_time | Yes |
| can_engine_revolutions | Yes |
| can_fuel_2 | Yes |
| can_fuel_temperature | Yes |
| can_intake_air_t | Yes |
| can_intercooler_temperature | Yes |
| can_oil_pressure | Yes |
| can_oil_temperature | Yes |
| can_road_surface_temp | Yes |
| can_sli_battery_net_current_1 | Yes |
| can_total_fuel_used | Yes |
| can_total_fuel_used_gas | Yes |
| can_total_power_takeoff_hours | Yes |
| can_trip_fuel_used | Yes |
| can_trip_fuel_used_gas | Yes |
| can_turbo_oil_temperature | Yes |
| can_washer_fluid_level | Yes |
| ext_temp_sensor_4 | Yes |
| hw_mileage | Yes |
| impulse_counter_2 | Yes |
| obd_absolute_load_value | Yes |
| obd_barometric_pressure | Yes |
| obd_consumption | Yes |
| obd_control_module_voltage | Yes |
| obd_coolant_t | Yes |
| obd_custom_fuel_litres | Yes |
| obd_custom_odometer | Yes |
| obd_engine_load | Yes |
| obd_fuel | Yes |
| obd_intake_air_t | Yes |
| obd_mil_run_time | Yes |
| obd_oil_temperature | Yes |
| obd_rpm | Yes |
| obd_speed | Yes |
| obd_throttle | Yes |
| obd_time_since_engine_start | Yes |
| raw_can_30 | Yes |
