GPS device
Suntech ST4915LCBF
SuntechThe Suntech ST4915LCBF asset tracker is a telemetry device specifically designed for managing fixed and mobile assets without a local power source with up to 7 years working time. It works with LTE-M and NB2-IoT networks and has Wi-Fi and Bluetooth connectivity options. ST4915LCBF has a built-in 3-axis accelerometer, extended battery life, and weather-resistant case.
Server connection
| EU platform | tracker.navixy.com (52.57.1.136) |
| US platform | tracker.us.navixy.com (13.52.37.2) |
| MENA platform | tracker.me.navixy.com (34.166.104.189) |
| Server port | 47728 |
| Auto registration | Yes |
General information
| Purpose | Asset |
| Weight | 714 g |
| Size | 62x258x61 mm |
| Waterproof class | IP67 |
| Internal antenna (GNSS) | Yes |
Features
| Satellites | Yes |
| Auto Registration | Yes |
| Board Voltage | Yes |
| Gprs Location Request | Yes |
| Odometer | Yes |
| Gsm Lbs | Yes |
| Gsm Signal Level | Yes |
| Motion sensor | Yes |
| Apn Settings | Yes |
| Sim Card | Yes |
State Fields
| State Fields |
|
Inputs and outputs
| alt_large_assign_8 | Yes |
| alt_medium_assign_8 | Yes |
| alt_small_assign_15 | Yes |
| board_voltage | Yes |
| hw_mileage | Yes |
| stt_large_assign_8 | Yes |
| stt_medium_assign_8 | Yes |
| stt_small_assign_15 | Yes |
