AMGPS BT-100

AMGPS BT-100 is light real-time tracking terminal with GNSS, GSM and Bluetooth connectivity which is able to collect device coordinates and other useful data and transfer them via GSM network to server. Bluetooth peripherals can greatly expand device functionality wirelessly. This device is perfectly suitable for applications where location acquirement of remote objects is needed: security, fleet management, car rental companies, taxi companies, public transport, logistics companies, personal cars and so on.

Show more

Location and tracking

AMGPS BT-100 model is embedded with GPS chip and also it has the support of GLONASS. It supports Assisted GPS (A-GPS) technology as well.

The tracking mode is flexible configured: by moving every 100m, and every 60 sec, and on turning on 30 degrees by default. When there is no movement (detected by “Ignition” status), tracker sends data every 180 seconds.

Mobile networks

With Quad-band GSM 2G module BT-100 can be operated all over the world.

Interfaces

Model features such interfaces as

  • Power supply 10-30V
  • 1 Digital Input
  • 1 Analog Input
  • 1 Digital Open-collector Output (connecting external relays, LED, buzzers etc.)
  • 2 LEDs indicating device status.

Harsh driving behaviour

Four scenarios are available on this device. Digital Output is used by scenarios – ECO driving/Green driving and/or Over Speeding;

ECO driving/Green driving Scenarios.

Helps to prevent and inspect driver about harsh driving. Eco driving scenario continuously monitors: accelerating, braking and cornering forces depending on build in accelerometer or Green driving depending on GPS. The device inspects driver if needed. Monitoring sensitivity is configurable.

DOUT1 is controlled by scenario for user needs, buzzer or LED for example. Output activation time after harsh event is also configurable.

To save GPRS traffic ECO driving/Green driving event will be generated (included into records) only when device measured values are higher than those set in configuration, without additional I/O settings.

To prevent generating false events, harsh acceleration and harsh braking is monitored only when following conditions are fulfilled:

  • Ignition is ON (DIN1 = 1)
  • Vehicle speed is equal or higher than 10km/h

Harsh cornering is monitored only when following conditions are fulfilled:

  • Ignition is ON (DIN1 = 1)
  • Vehicle speed is equal or higher than 30km/h ECO driving or Green driving Scenario? Eco driving is based on accelerometer value and Green driving based on GPS position.

Over Speeding Scenario.

Helps to prevent from exceeding fixed speed and inspects driver if needed. DOUT1 is controlled by scenario for user needs, to manage buzzer, LED, etc.

Features

  • Bluetooth transceiver fully compliant with Bluetooth specification V3.0 for external peripherals
  • Supported up to 4 BLE temperature, humidity or fuel sensors.
  • Up to 32 GB micro SD memory card for up to 275 million records
  • IP54 certified case
  • Fully controllable digital output via SMS and configurator
  • Ultra small and easy to mount in limited access areas case
  • Fast first GPS fix
  • Real Time tracking
  • Sending acquired data via GPRS (TCP/IPand UDP/IPprotocols)
  • Smart algorithm of GPRS connections for GPRS traffic saving
  • Operating in roaming networks by preferred GSM providers list
  • Events from I/O elements detection and sending via GPRS or SMS
  • Auto Geofencing and Towing Detection for car theft prevention
  • Deep Sleep mode (less than 2 mApower consumption)
  • Firmware and configuration update via GPRS
  • Smart data acquisition mode
  • Color Ribbon undetachable cable
  • Easy to mount
  • Configuration via Bluetooth
  • Crash detection
  • Towing detection using accelerometer
  • Smart data acquisition based on:
    • Time
    • Distance
    • Angle
    • Ignition or any other I/O events
  • Configurable using Secured SMS commands and configurator on PC

LED Indication

  • Status LED: indicates GSM/GPRS mode
  • Navigate LED: indicates GPS reception

Server connection

EU platformtracker.navixy.com (52.57.1.136)
US platformtracker.us.navixy.com (13.52.37.2)
Server port47776
Auto registrationYes

General information

PurposeVehicle
Size79x43x12 mm (3.11x1.69x0.47 in)
Waterproof classIP5X
Internal antenna (GNSS)Yes
Internal antenna (Connection)Yes

Connectivity information

Roaming statusYes
Network signal levelYes
Cellular network typeGSM Quad Band
Cellular network generation2G

Location information

GNSS signal levelYes
LBSYes
Forced GNSS location update over GPRSYes
Forced GNSS location update over SMSYes
GPSYes
GLONASSYes
Assisted GPSYes

Features

Remote outputs controlYes
OdometerYes
Motion sensorYes
Hardware keyYes
Built-in batteryYes
Battery capacity170 mAh

Interfaces

Discrete inputs2
Number of outputs1
Analog sensorYes
Impulse counterYes
Frequency sensorYes
CAN/OBDII reader typeExternal
