Server connection details

Supported features

Server Integration
Server Addresstracker.navixy.com
Server IP Address217.23.132.215
Server port47738
General information
PurposeVehicle
InstallationProfessional
Housing
Weight92 g (3.25 oz.)
Size75x54x25 mm (2.95x2.13x0.98 in)
GNSS Location
External antenna (GNSS)
GPS
Connectivity
Cellular network typeGSM Quad Band
Cellular network generation2G
Interfaces
RS232 interface
Number of RS232 interfaces1
Number of outputs2
Number of inputs (all types)4
ACC/Ignition input
Feature already supported
Discrete inputs
Feature already supported
Analog inputs
Feature already supported
Hardware features
Emergency buttonOptional, Yes
Feature already supported
Hardware extras
Fuel level sensor reading
Feature already supported
Voice listening
Feature can be supported upon request
Driver ID reading
Feature can be supported upon request
Tracking features
Tracking modesContinuous
Odometer
Feature can be supported upon request
ECO driving
Feature already supported
Events monitoring
Battery low
Feature already supported
External power cut off
Feature already supported
Car crash
Feature can be supported upon request
Self monitoring
GNSS signal level
Feature already supported
Remote management
Server connection setup over SMS
Feature already supported
Remote outputs control
Forced GNSS location update over SMS
Feature already supported

How to connect to Navixy server

Automatic activation (recommended)

The software platform supports automatic device activation by applying APN settings, server address and port, as well as recommended tracking mode though the SMS channel. Normally you don’t need to configure anything manually. Just install the SIM card, switch the device ON and make sure it is located in the place with good GPS signal reception.

You also need to keep the device with initial factory settings, in particular:

  • Do not set any password, keep it clear (as by default)
  • Do not set any master number prior to the device activation
  • Do not set local Time zone, it must be UTC+0h (as by default)

Manual activation

In case automatic activation failed, you can try to register the device manually by sending following commands to the device:

W000000,011,<APN>,<APN name>,<APN password>
W000000,012,217.23.132.215,<port>,<port>
W000000,013,1

The <APN> parameters depend on your GSM carrier.
