CalAmp LMU-300

The LMU-300 is an economical, full-featured vehicle tracking product designed for covert and reliable installation in automobiles. The LMU-300 is an ideal solution for stolen vehicle, vehicle finance, auto rental and other automotive track and trace applications.

Show more

Location and tracking

  • GPS Support
  • Continuous tracking mode
  • LBS Support

Mobile networks

  • 850/900/1800/1900 MHz
  • 2G/3G Network

Power supply

  • Build-in battery (200/1000 Li-Ion)
  • External power supply (9-32 V)

Inputs and outputs

  • 2 Discrete inputs
  • 1 Digital outputs

Other features

  • Remote management
  • AGPS

Server Integration

EU platformtracker.navixy.com (52.57.1.136)
US platformtracker.us.navixy.com (13.52.37.2)
Server port47710

General information

PurposeVehicle
InstallationProfessional

Housing

Weight87 g (3.07 oz.)
Size46.5x83.6x19.4 mm (1.83x3.29x0.76 in)

GNSS Location

Internal antenna (GNSS)Yes
GPSYes
Assisted GPSYes

Connectivity

Cellular network typeGSM Quad Band
Internal antenna (Connection)Yes
Cellular network generation2G

Interfaces

Number of outputs4
Number of inputs (all types)3
Discrete inputsYes
Supported

Tracking features

Tracking modesContinuous
Location by Cell IDYes
Supported

Self monitoring

Network signal levelYes
Supported
Network operator IDYes
Supported
GNSS signal levelYes
Supported
External power source voltageYes
Supported

Remote management

Server connection setup over SMSYes
Supported
Remote device configurationYes (over GPRS)
Supported
Remote outputs controlYes (over GPRS)
Supported
Forced GNSS location update over SMSYes
Supported
